Fluke 718 300G Pressure Calibrator Pressure Calibration Tools Pressure Calibrators



Similar Types : Fluke 750P, Fluke 754, Fluke 753, Fluke 726, Fluke 725, Fluke 725Ex, Fluke 719, Fluke 700PTPK, Fluke 700HTPK, Fluke 700G, Fluke 721, Fluke 719Pro, Fluke 717, Fluke 718, Fluke 718Ex, Fluke 3130-G2M, Fluke 3130-G2M, Fluke P3000, Fluke P3100, Fluke P3800, Fluke P3200, Fluke P5510, Fluke P5513, Fluke P5514, Fluke P5515, Fluke E-DWT



The Fluke 718 Pressure Calibrator provides total pressure calibration solutions for transmitters, gauges, and switches.



The complete solution to pressure calibration

The Fluke 718 Pressure Calibrator provides a total pressure calibration solution for transmitters, gauges and switches. This compact pressure calibration solution is about a third of the size of comparable instruments and weighs just one kilogram (two pounds). The unique easy to clean pump helps protect the pump from damage and provides the ability to service the pump without disassembly, even in the field.



Features

Pressure Source and Milliamp Measurement to calibrate and maintain almost any pressure device

Integrated pump is easily cleaned when accidently exposed to fluids that reduces cost of ownership and repairs and enables servicing the pump in the field

Error % calculation for quicker pass/fail decision making in the field

Best in class mA accuracy of 0.015% for better measurement confidence and workload coverage

Min/Max/Hold to capture changing measurements

Switch test feature for quicker and more accurate pressure switch testing

New 1 and 300 psi pressure ranges mean fewer extra tools required

1, 30, 100 & 300 psi ranges now available



Technical Specifications


Fluke 718 Series

(Internal sensor)

Measure pressure

0.025% full scale

Functions

Zero, min/max, hold, damp

Dry air, non-corrosives only


Fluke 718 1G


Range

-1 psi to +1 psi, -68.9 mbar   to 68.9 mbar (-6.89 kPa to 6.89 kPa)

Resolution

0.0001 psi, 0.001 mbar,   0.0001 kPa

Over pressure

5x Full Scale

Functions

Zero, Min, Max, Hold, Damp

Fluke 718 30G


Range

-12 psi to 30 psi, (-850   mbar to 2 bar, -85 to 206.84 kPa)

Resolution

0.001 psi, 0.1 mbar, 0.01   kPa

Over pressure

5x Full Scale

Functions

Zero, Min, Max, Hold, Damp

Fluke 718 100G


Range

-12 psi to 100 psi, (-850   mbar to 7 bar, -85 to 689.48 kPa)

Resolution

0.01 psi, 0.1 mbar, 0.01 kPa

Over pressure

2x Full Scale

Functions

Zero, Min, Max, Hold, Damp

Fluke 718 300G


Range

Functions

Resolution

0.01 psi, 1 mbar, 0.1 kPa

Over pressure

375 psi 25 bar

Functions

Zero, Min, Max, Hold, Damp

Fluke 718 series via 700 Series Pressure Modules


Range

29 pressure modules, 0 – 1   inH20 to 10,000 psi, 2.5 mbar to 700 bar. Over pressure per pressure module   specs

Resolution

Per pressure module specs

Accuracy

To 0.025% of full span, per   pressure module specs

Functions

Zero, Min, Max, Hold, Damp

Media compatibility per   pressure module specs


Fluke 718 Series Via Built in Pump


Range

-12 psi or -850 mbar to full   scale Supported Pressure Units; psi, inH20 (4°C), inH20 (20°C), cmH20 (4°C),   cmH20 (20°C), bar, mbar, kPa, inHg, mmHg, kg/cm

Loop power range

24 V DC

Accuracy

±10%

Drive; 20 mA into 1000 Ω for   battery > 6.8 V; 700 Ω for battery 5.8 to 6.8 V


mA Measure


Range

0 mA to 24 mA

Resolution

0.001 mA

Accuracy

0.015% + 1 count

General Specifications


Maximum voltage

30 volts (non-operating)

Temperature

-40°C to 60°C

Operating temperature

-10°C to 55°C

Relative humidity

95% (10°C to 30°C); 75%   (30°C to 40°C); 45% (40°C to 50°C); 35% (50°C to 55°C)

Operating altitude

3,000 M max

Shock

1 M drop test

Vibration

Random, 2 g, 5 Hz – 500 Hz

Safety

CSA C22.2 No. 1010.1: 1992

EMC

EN50082-1: 1992 and EN55022:   1994 Class B

Size

216 x 94 x 66 mm (8.50 x   3.72 x 2.60 in)

Weight

992 g (35 oz)

Power, battery life

9V battery ANSI/NEDA 1604A   or IEC 6LR619V alkaline; two batteries in 718

Battery life

4 to 20 hours typical,   depending on functions used

Warranty

Three years (one year on   pressure pump in Fluke 718)

Display

LCD, 5 digit pressure and   current simultaneous

For use with non-corrosive   gasses
